Automatic Sensor Taps

All the taps shown here, apart from the "1D" model, are from KWC DVS (formerly Dart Valley Systems), who we regard as the current leader in design and manufacture of taps for public washrooms with high usage.

1D Sensor Operated Tap - Mains and Battery Supply

1D Sensor Operated Tap - Mains and Battery Supply

SEN-1D
Sensor 1D Automatic Tap, Mains & battery powered
Compact and solid in design, the 1D is ideal for hand sinks in rest areas, stadiums, schools, restaurants, hotels and other public areas.

Features
• Mains operated with battery back-up
• Vandal and scratch resistant sensor window
• Moisture and water resistant control unit
• Suitable for cold or premixed water
• Maximum operational temperature 45°C
• Minimum pressure required 0.5 bar
• 12 Month return to base warranty
• WRAS Approved


Pressures & operating conditions:
Inlet connection: ½” BSP
- Working pressure: 1.0 - 5.0 bar
- Minimum flow rate: 5 LPM
- Tap hole Size: 35mm drill hole

Data sheet
Installation and Maintenance Guide

£175.00

 (ex VAT)
KWC DVS Aquarius A45 Deck Mounted Automatic Tap

KWC DVS Aquarius A45 Deck Mounted Automatic Tap

A45MS

Aquarius A45 Automatic Sensor Tap - Mains Powered

Not Available to order Until Mid-August

Incorporating a modern and simple design, the A45 tap ensures the ultimate in hygiene for the most discerning of clients. Perfect for all applications where hygiene is paramount. The robust design and build quality also makes it ideal for heavy industrial applications. The A45 is manufactured from stainless steel, and with a solid 38mm stainless steel ingot for the head assembly. Please see "Diagrams" tab for tap measurements.
The integrated sensor comes pre-set, and additional settings can be programmed on site using the hand-held programmer (sold separately), these settings include increased run-on times, and anti-vandal lock out functions.
These A45 taps have the IR sensor located at the end of the tap pointing downward to reduce the risk of false activations caused by reflective materials such as hi-vis jackets.

Water Pressure: The standard solenoid valve supplied has a pressure rating range of 1.0 Bar to 6.0 Bar, and a minimum flow rate 5 L/min per tap.

Electrical Requirements: Each kit requires a 3-amp protected fused spur.

Tap Hole Size: 28mm

Pack Includes:

- Tap(s) - AT03-011
- Solenoid valve(s)
- Power supply unit (PSU)
- Connector(s) for PSU
- Flex hose(s)

£310.00

 (ex VAT)
KWC DVS Aquarius Wall Mounted Automatic Tap

KWC DVS Aquarius Wall Mounted Automatic Tap

1XAT02-001+AT00-002

Aquarius Wall-Mounted Automatic Sensor Taps - 150mm and 200mm

With its modern and simple design, the Aquarius Wall Mounted tap ensures the ultimate in hygiene for the most discerning of clients. It is manufactured from stainless steel with a solid 38mm stainless steel ingot for the head assembly. Standard finish for this tap is brushed, but polished is available as an extra. This tap is available in two lengths; 150mm and 200mm.

The integrated sensor comes pre-set, and additional settings can be programmed on site using the hand-held programmer (sold separately), these settings include increased run-on times, and anti-vandal lock out functions.
These taps have the IR sensor located at the end of the tap pointing downward to reduce the risk of false activations caused by reflective materials such as hi-vis jackets.

Water Pressure: The standard solenoid valve supplied has a pressure rating range of 1.0 Bar to 6.0 Bar, and a minimum flow rate 5 L/min per tap.

Electrical Requirements: Each kit requires a 3-amp protected fused spur.

Pack Includes:

- Tap(s)
- Solenoid valve(s)
- Battery or power supply unit (PSU)
- Connector(s) for battery or PSU
- Flex hose(s)


Options:

- Length: 150mm or 200mm
- One, two or three stations
- TMV3 thermostatic mixer valve
- Isolation valve and Y-strainer

Click PDF icon to view instruction manual.

DVS Automatic Tap Instruction Manual

£319.00

 (ex VAT)

Automatic Sensor Taps

KWC DVS taps are built for busy washrooms which is why they are so often seen at airports and motorway service stations. They also offer resistance to vandalism and misuse due to the heavy duty construction. Easy to install, with options for mains or battery operated, KWC DVS No-Touch products allow you to control your water efficiently, conserve energy and cut costs without sacrificing performance and reliability.

No-Touch automatic taps and accessories from KWC DVS (formerly Dart Valley Systems) incorporate state-of-the-art design and technology and provide hygienic water dispensing solutions to many market sectors - including hotels, supermarkets, laboratories, hospitals, schools, universities, airports, motorway services and food factories to name a few. Gentworks uses KWC DVS products for most of the large water saving projects we carry out because of the wide range of options and exceptional reliability.

For more details of the range, including tap diagrams, applications, how they work and the benefits, please  view the brochure.
