Direct Mains Water Supply Controls for Individual Urinals

Individual urinal control systems are the ultimate in water saving through sensor operated flushing. A flush is activated only after someone has approached and then walked away from the bowl, or if nobody has used the urinal for 12 hours. These systems are usually operated straight from the mains water supply (i.e. without a cistern) but certain models can be used with float cisterns (not the autosiphon cisterns normally supplied with urinals). As the bowl will typically be flushed before the next user approaches the urinals, these individual sensor controls are ideal for use with siphonic urinals that leave urine showing until the next flush.
Cistermiser Direct Flush 'Discreet' PIR Urinal Control

Cistermiser Direct Flush 'Discreet' PIR Urinal Control

CM-DFD

The 'Discreet' version of the Cistermiser Direct Flush incorporates valve, power options and sensor for duct mounting. An 'accessible' version is also available. Gentworks recommends that this unit is only installed by experienced plumbers or similar contactors because dynamic water pressure needs to be at a satisfactory level to enable them to perform to specification.

The Cistermiser Direct Flush Infrared Sensor Controlled Urinal Valve is a simple economic solution to ensure urinal hygiene and water economy. It provides automatic flushing of the

 individual urinal after use ensuring the highest level of hygiene from the minimum volume of water directly from the mains water supply. Direct Flush removes the need for the auto-flush cistern and associated plumbing used in traditional urinal installations which flush all urinals regardless of usage.

Not suitable for exposed pipework installations

Pack Includes :
- Valve.
- Battery or Mains options in same kit .
- Infra-red Sensor

See the 'More Product Info' tab for additional information and a list of product features

£192.00

 (ex VAT)
KWC DVS Pearl SOLO Downlighter For Direct Flush - Ceiling Mounted UC01-027

KWC DVS Pearl SOLO Downlighter For Direct Flush - Ceiling Mounted UC01-027

UC01-027

The KWC DVS UC01-027 Pearl Solo is a suspended ceiling urinal control for a single urinal bowl without a cistern. This mains powered unit is the size of a mini-downlighter, with a narrow beam, and will only be activated if a user stands under the beam for 5 seconds or more.  When the user walks away there is a 3 second delay before the controller flushes for the set number of seconds.

For concealed installations where the flush pipe and spreader water connection are hidden behind panels or a stud wall, it is recommended to use a Pearl Solo unit for each urinal. To avoid interference, make sure to position LED lights away from these IR devices.

Includes:

- Solenoid valve for connection to water supply
- Sensor, incorporating flush controller system, for fitting into ceiling above urinals
- power transformer

Features:
- Up to 80% savings on water costs
- Extremely reliable and low maintenance
- Passive infra-red sensor, detection indicated by a flashing green light
- Low power consumption
- Single valve output
- Default pre-set settings
- adjustable flush period
- Valve open button
- Janitorial flush (if sensor not triggered for 12 hours)

Air Break (back-flow preventer): Required to comply with water regulations to prevent contamination of mains water supply.

Isolators and Filters: These are standard plumbing fittings but can be added as an option for convenience. It is recommended that an isolation valve is fitted either side of the solenoid valve. If the water flow through the solenoid valve is too fast, spillage from the air break may result. To remedy this, the isolation valve after the solenoid valve should be adjusted to reduce the flow. Restricting the flow using the isolation valve before the solenoid valve may cause the soelnoid valve to operate incorrectly. It is also recommended that a Y-filter is fitted before the solenoid valve to prevent debris from constricting the flow through the solenoid valve or urinal spreader.

£249.00

 (ex VAT)
KWC DVS Individual Urinal Sensor - Direct Flush - 1 bowl

KWC DVS Individual Urinal Sensor - Direct Flush - 1 bowl

UC07-010

This individual operation urinal control system is designed to flush a single urinal directly from the mains water supply. No cistern is required. The urinal is flushed when the user walks away. The units are extremely versatile in their operation and we have found them to be very reliable indeed. The design and manufacturing quality are excellent. The installation process is a little more demanding than for some competitive products but that extra time is well spent to ensure the system works as required and continues to do so. Moreover, variable settings allow adjustable time delays between flushing, providing maximum efficiency and savings.

To prevent interference, position LED lights away from these IR devices and ensure they are not in the direct path of IR beams.

Pack includes:

  • 1 x Urinal control system box with built-in power supply
  • 1 x Passive infra-red sensor with 50mm diameter stainless steel bezel suitable for up to 50mm thick wall boards / panels.
  • 1 x Solenoid valve
  • 1 x 3 metre cable
  • Spade connectors
DVS Urinal Control System Instruction Manual

            DVS Urinal Control System Instruction Manual (492k)

£279.00

 (ex VAT)
KWC DVS Individual Urinal Sensor - Direct Flush - 2 bowls

KWC DVS Individual Urinal Sensor - Direct Flush - 2 bowls

UC07-011

This individual operation urinal control system is designed to flush a single urinal directly from the mains water supply. No cistern is required. The urinal is flushed when the user walks away. The units are extremely versatile in their operation and we have found them to be very reliable indeed. The design and manufacturing quality are excellent. The installation process is a little more demanding than for some competitive products but that extra time is well spent to ensure the system works as required and continues to do so. Moreover, variable settings allow adjustable time delays between flushing, providing maximum efficiency and savings.

To prevent interference, position LED lights away from these IR devices and ensure they are not in the direct path of IR beams.

  • 1 x Urinal control system box with built-in power supply
  • 2 x Passive infra-red sensor with 50mm diameter stainless steel bezel suitable for up to 50mm thick wall boards / panels.
  • 2 x Solenoid valves
  • 2 x 3 metre cables
  • Spade connectors
DVS Urinal Control System Instruction Manual

            DVS Urinal Control System Instruction Manual (492k)

£345.00

 (ex VAT)
