Wash Troughs

Our range of wash troughs are space efficient, easy to clean and more hardwearing than conventional basins incorporated in vanity units. Wash troughs are particularly popular within education, hospitality and other buildings with high traffic washrooms. If you’re in a hurry for a wash trough then take look at our quick delivery range.

Stainless Steel Wash Trough - 4 Lengths Available From Stock

Stainless Steel Wash Trough - 4 Lengths Available From Stock

GW-WDT12A-C-28S2

New Range of Stocked High-Quality Wash Troughs Coming Soon in Early June!

Improve handwashing capacity swiftly and cost-effectively with our wall-hung stainless steel wash trough.

These wash troughs are made from 1.2mm thick, 304 stainless steel with a satin finish, featuring pre-drilled 28mm single tap holes for single inlet feed taps and most water-saving non-concussive push taps. Not suitable for pairs of taps or monobloc mixer taps with twin feed inlets; for those, please explore our made-to-order range.



• Quick delivery - ready stock available
• Pre-drilled single 28mm tap holes for single feed inlet taps
• Available in four lengths
• Safety edges all round
• Tap ledge
• Optional front support legs
• Fully welded construction
• Integral wall fixing brackets
• Anti-splash design
• Central 1.5” BSP waste, 2400mm version has a handed waste

Dimension:
Projection from wall = 370mm
Height = 155mm
Internal Trough Depth = 130mm max.

A 25mm upstand to the rear allows taps to be mounted on an easy to clean surface. Front legs with bearer brackets are available if additional support is required.

Tap holes and waste outlet configurations:
Our most popular tap setup for stainless steel wash troughs is a single non-concussive tap per user, connected to either cold water or, when hot water is available, a thermostatic mixing valve (TMV) to achieve the optimal hand washing temperature of approximately 43 degrees Celsius. These wash troughs, with pre-cut single 28mm tap holes, ensure a secure fit for single feed taps, minimising the risk of movement or twisting.
- 1200mm Wash Trough – 2 tap-holes with centre waste
- 1500mm Wash Trough – 3 tap-holes with centre waste
- 1800mm Wash Trough – 3 tap-holes with centre waste
- 2400mm Wash Trough – 4 tap-holes with option of left or right hand waste


Pack Includes:

- Wash Trough with 28mm Tap Holes
- 38mm (1.5") BSP Unslotted Waste Outlet fitting

£329.00

 (ex VAT)
Quick Delivery 1500mm "B"  Range Wash Trough with 28mm Single Tap Holes

Quick Delivery 1500mm "B" Range Wash Trough with 28mm Single Tap Holes

WMDT1500B-C-28S2MTS-

Quick Delivery 1500mm "B" Range Economy Wash Trough with 3x 28mm Single Tap holes
An economy model wash trough designed for high-use areas. It has an angled front to reduce splashing and is designed to allow users to wash their hands, face, and forearms effectively. These wash troughs are popular in construction welfare facilities and other similar settings.

If you require a different size or tap hole options and can wait longer, please see our "B" Range Wash Trough in related products below.

Tap Holes:
3x 28mm Single Tap holes for single feed taps with cold only or mixed water supply via a thermostatic mixing valve (not suitable for Hot & Cold Pairs of taps)

• Tap ledge pre-drilled with 3x single 28mm tap holes
• Integral Wall Fixing Brackets
• Anti-splash Design
• Centre Waste Location

All our Wash troughs are manufactured in the UK as one piece units from grade 304 austenitic stainless steel, 1.2mm thick and a non-reflective surface.

Projection from wall = 410mm Height = 215mm (including 60mm high splashback)
Trough Depth = 155mm max.

Pack Includes:
- 1500mm Wash Trough with 3x 28mm Single Tap Holes
- 38mm (1.5") BSP  Unslotted Flush Grated Waste Outlet
- Mounting Brackets

Please check delivery restrictions in the "About Delivery" tab before ordering.

£340.00

 (ex VAT)
GRP Wash Trough - Wall Mounted - 3 Lengths Available

GRP Wash Trough - Wall Mounted - 3 Lengths Available

GW-GRPT12W-

Manufactured in Glass Fibre Reinforced Polyester Resin (the same material as often used for boat hulls), this wash trough has a smooth gel-coat finish that is resistant to staining and damage. Its smooth design enables easy cleaning without the requirement for strong cleaning products. The Gentworks GRP wash troughs are ideal for use in washrooms where aesthetics are important. They are particularly popular in the education sector and for modular buildings.

• Supplied in 3 lengths
• Tap ledge for deck mounted taps
• Supplied without tap holes
• Lightweight and extremely durable
• Includes wall fixing brackets
• Smooth gel-Coat finish
• Central 2” BSP waste outlet

Tap Holes: Now supplied without tap holes, these can easily be drilled on site as part of the installation.

Dimension:
Projection from wall = 429mm
Height = 295mm
Internal Bowl Depth = 170mm

Pack Includes:
- wash trough
- 2" BSP waste outlet fitting
- 2 x Handed wall brackets

£395.00

 (ex VAT)
1200mm Solid Surface Wash Trough for Cabinet Mounting

1200mm Solid Surface Wash Trough for Cabinet Mounting

GW-SLDSF1200-W

1200mm long Solid Surface Wash Trough for Cabinet or Underframe Mounting

Renowned for their exceptional durability, robustness, and aesthetics, our solid surface wash troughs are the ultimate premium choice.

Projection from wall = 400mm Height = 166mm Product Weight = 28kg
Internal Bowl Depth = 110mm Material Thickness = 14mm

• 1200mm Length Suitable For 2 Users
• White Gloss Finish
• For Cabinet / Underframe Mounting (Not Supplied)
• Stylish Design With Contoured Base
• Premium Solid Surface Material
• Constructed WITHOUT Timber, Plywood, or MDF
• Seamless and Joint-free Design
• Built-in Upstand Prevents Water Runoff Onto The Wall
• Suitable For Deck or Wall Mounted Taps
• Multiple Outlets Eliminate The Need For Unhygienic Overflow Holes
• Supplied With 2 Chrome Waste Outlets
• Made In The U.K.

 The Gentworks GW-SLDSF1200 wash trough is manufactured from a 14mm thick solid surface material. Solid surface is a generic name given to material produced by combining polymer resins with marble and limestone.

The wash trough is space efficient, easy to clean and more hardwearing than conventional vanity units that incorporate basins. This model is intended for installation onto an underframe or vanity-type cabinet (not included) to ensure proper support and conceal unsightly pipework and plumbing fittings from view.

This heavy and durable solid surface wash trough features a gel coat to achieve a beautiful white finish that is non-porous and resistant to staining and yellowing. The inherent properties of the material also make this model more resistant to the growth of bacteria. Moreover, its 'repairable' quality means that stains or scratches can usually be easily removed.

The wash trough is supplied without tap holes but can easily be drilled on-site by the installer to suit your chosen taps.

Sample specification Text

Gentworks Solid Surface White Hand Wash Trough For Cabinet or Underframe Mounting -1200mm(L) x 400mm (W) x 166mm (H) and 20mm Rear Upstand Lip. Supplied Undrilled For Wall Mounted Taps or Can Be Drilled For Deck Taps. Supplied with 2x 32mm Chrome Wastes. Product Code GW-SLDSF1200-W

Pack Includes:
- 1200mm wash trough
- 2x 1 -1/4" BSP chrome un-slotted waste outlets

(Underframe cabinets and taps are not included and are shown for illustrative purposes only)

THIS PRODUCT IS USUALLY DELIVERED IN 2-3 WORKING DAYS VIA OUR STANDARD PALLET SERVICE
Please check pallet service delivery restrictions in the "About Delivery" tab before ordering.

£495.00

 (ex VAT)
1800mm Solid Surface Wash Trough for Cabinet Mounting

1800mm Solid Surface Wash Trough for Cabinet Mounting

GW-SLDSF1800-W

1800mm long Solid Surface Wash Trough for Cabinet or Underfame Mounting

Renowned for their exceptional durability, robustness, and aesthetics, our solid surface wash troughs are the ultimate premium choice.

Projection from wall = 400mm    Height = 166mm  Product Weight = 35kg
Internal Bowl Depth = 110mm  Material Thickness = 14mm

• 1800mm Length Suitable For 3 Users
• White Gloss Finish
• For Cabinet / Underframe Mounting (Not Supplied)
• Stylish Design With Contoured Base
• Premium Solid Surface Material
• Constructed WITHOUT Timber, Plywood, or MDF
• Seamless and Joint-free Design
• Built-in Upstand Prevents Water Runoff Onto The Wall
• Suitable For Deck or Wall Mounted Taps
• Multiple Outlets Eliminate The Need For Unhygienic Overflow Holes
• Supplied With 3 Chrome Waste Outlets
• Made In The U.K.

The Gentworks GW-SLDSF1800 wash trough is manufactured from a 14mm thick solid surface material. Solid surface is a generic name given to material produced by combining polymer resins with marble and limestone.

The wash trough is space efficient, easy to clean and more hardwearing than conventional vanity units that incorporate basins. This model is intended for installation onto an underframe or vanity-type cabinet (not included) to ensure proper support and conceal unsightly pipework and plumbing fittings from view.

This heavy and durable solid surface wash trough features a gel coat to achieve a beautiful white finish that is non-porous and resistant to staining and yellowing. The inherent properties of the material also make this model more resistant to the growth of bacteria. Moreover, its 'repairable' quality means that stains or scratches can usually be easily removed.

The wash trough is supplied without tap hole but can easily be drilled on site by the installer to suit your chosen taps.

Delivery will be arranged to your site via dedicated transport to reduce the risk of damage. If you're in an area not showing as available for delivery, please contact us for a quote.

If you require more than one please contact us as for quote as the delivery charge for additional units (if applicable to your area) will be reduced or at no extra cost.

Sample specification Text
Gentworks Solid Surface White Hand Wash Trough For Cabinet or Underframe Mounting -1800mm(L) x 400mm (W) x 166mm (H) and 20mm Rear Upstand Lip. Supplied Undrilled For Wall Mounted Taps or Can Be Drilled For Deck Taps. Supplied with 3x 32mm Chrome Wastes. Product Code GW-SLDSF1800-W

Pack Includes:
- 1800mm wash trough
- 3x 32mm BSP chrome un-slotted waste outlets

 (Underframe cabinets and taps are not included and are shown for illustrative purposes only)

£595.00

 (ex VAT)
