Taps

Self closing non-concussive single feed tap is manufactured from brass and has a high polish chrome finish.

Provides approximately 8-10 seconds duration of flow (not adjustable) when the push button top is depressed, savings in both water usage and energy in all commercial and industrial environments.
This tap is supplied with cold and hot indices for either installation.
Inlet Connection - Single Feed (1/2 in) BSP male connection.

WRAS Approved.

Features:
- Self closing operation
- Water & Energy saving
- High polish chrome finish

Pressures & operating conditions:
Minimum operating pressure: 0.5 bar
Maximum operating pressure: 3.0 bar
Maximum Inlet temperature: 43^oC

This monobloc sequential mixing tap is manufactured from brass and has a high polish chrome finish.  The tap features a single lever sequential spray mixer providing cold to hot through 180 degree operation of the lever. The lever handle is easy to grip and can be operated by either hand or wrist making the tap ideal for those with limited dexterity.

Cold start technology:
Cold start taps reduce energy waste and save money by only activating cold water when opened centrally. Hot water is still available by turning the lever further. This technology is especially useful for daily tasks like handwashing and teeth brushing, eliminating unnecessary heating and changing our approach to warm water usage.

The mixer tap is not thermostatic and a proprietary temperature control device (TMV) should always be used.

Features:
- Simple easy to grip lever operation
- Cold start technology
- WRAS approved
- 35mm tap hole required
- Supplied with flexible water inlet hoses
- High polish chrome finish

Pressures:
Minimum operating pressure: 1.0 bar
Maximum operating pressure: 6.0 bar
Recommended operating range 2.0 to 5 bar
Flow rate at 1 bar = 2.0 ltr per minute

This self-closing toggle lever handle deck mounted tap is easy to grip and can be operated by either hand or wrist making the tap ideal for those with limited dexterity and a great choice for primary schools and nurseries.

The toggle tap is not thermostatic and must be installed to pre-mixed water with a control device (TMV).

Features:
- Chrome plated
- WRAS Approval Number: 2106004
- Single feed 1/2" BSP connection
- 22mm/28mm tap holes required
- Approx. 8-12 seconds time flow
- Multi directional lever
- Supplied as single tap
- Easy for young children to operate
- Idea for use in unsupervised areas to stop water wastage

Technical Specification:
Max operating pressure: 5.0 bar static
Min operating pressure: 0.5 bar dynamic
Max inlet temperature: 80°C
Timed flow: 8/12 seconds

Delabie Temposoft 2 Deck-Mounted Push Tap – A sleek, modern tap with easy soft-touch push-button activation.

Supplied with red and blue markers – Suitable for cold or mixed warm water feed
Soft-touch operation – Easy to use with minimal effort
Automatic shut-off (~7 seconds) – Reduces water waste and running costs
Tamperproof & scale-resistant flow straightener
WRAS Approved – Certification: 2304074

This is a single-feed tap for either cold or pre-mixed warm water. To regulate temperature for warm water supply, we recommend using a TMV3 thermostatic mixing valve. Please note, this is not a mixer tap.

Pressure & Operating Conditions:
Recommended pressure range – 1 to 5 bar
Pre-set flow rate – 3 LPM at 3.0 BAR
Flow time 7 seconds
Tap Hole Size - 22-28mm

Thermostatic Sequential Basin Mixer Tap with Integral Thermostatic mixing valve.

This tap features an integral thermostatic mixing valve (TMV) within the body, eliminating the need for a separate TMV in the supply pipework. It provides precise temperature control, enhances water hygiene, and streamlines installation.

Features:
- Integral Thermostatic mixing valve
- TMV3 Approved
- 35mm tap hole required
- Supplied with copper inlet tails
- High polish chrome finish

Height:132mm
Depth: 153mm

Pressures:
Minimum operating pressure: 1.0 bar
Maximum operating pressure: 6.0 bar
Recommended operating range 2.0 to 5 bar

Self closing exposed connection knee operated timed flow valve with basin / deck spout. Suitable for commercial and industrial environments and for those with restricted hand movement.

Valve:
The through wall mounted lever articulates in any direction and each activation gives approximately 15 seconds flow. Manufactured from brass with a chrome plated finish and suitable for connecting to a temperature controlled warm water supply.

A multi directional lever operated valve allows the user to deliver hot, cold or mixed temperature water in a controlled and hygienic way. The valves are simple to install, easy to use, vandal resistant and durable making them ideal for wide range of applications.

Inlet and outlet are compression fittings to suit 15mm diameter pipe. WRAS Approval Number: 2011057

Deck Spout Options: Choose from two deck-mounted tap styles or a standalone knee valve. Both tap spouts from the options above require a 22-28mm tap hole.

Pressures and Operating Conditions:
Maximum operating pressure: 5 bar
Minimum operating pressure: 0.5 bar
Maximum inlet Temperature: 65oC
Timed flow at 1 bar: 15 ± 3 seconds
